NM360, NM400, NM450, NM500, NM600 Abrasion Resistant Steel Plate For Sale

Wear-resistant steel plate is a type of steel specially designed to resist abrasion and impact and is widely used in fields such as heavy industry and mining.

Product Name: High Quality Low Price Hard-faced Wear Plate The Wear Plate The Boiler Wear Plate.

GB: NM300, NM360, NM400, NM450, NM500.

DIN: XAR400, XAR450, XAR500, XAR600, Dillidur400, Dillidur500.

NBN: QUARD400, QUARD450, QUARD500.

NF: FORA400, FORA500, Creusabro4800, Creusabro8000.

SFS: RAEX400, RAEX450, RAEX500.

Capacity: 4,500 tons/Month.

Share This Page:

Abrasion Resistant Steel Plate Description

Wear-resistant steel plate is a kind of steel specially designed to resist wear and impact, and is widely used in heavy industry and mining. The following is a detailed introduction of wear-resistant steel plate:
Features:
High hardness: Wear-resistant steel plates usually have high hardness, which can effectively resist the wear of objects and extend the service life.
Impact resistance: In addition to wear resistance, wear-resistant steel plates also have good toughness and can withstand certain impact forces.
Corrosion resistance: Some types of wear-resistant steel plates have been specially treated to have certain corrosion resistance and are suitable for harsh environments.
Weldability: Despite the high hardness, many wear-resistant steel plates still have good welding performance, which is convenient for connecting with other materials.

Abrasion Resistant Steel Plate Technical

Steel/Grade C Si Mn P S AL Cr+Ni+Mo Nb+V+Ti
NM360/AR360 0.10-0.30 0.20-0.40 1.00-2.00 ≤0.015 ≤0.003 ≥0.20 <0.6 Trace Amount
NM400/AR400 0.10-0.40 0.20-0.40 1.00-2.00 ≤0.015 ≤0.003 ≥0.20 <0.9
NM450/AR450 0.10-0.40 0.20-0.40 1.00-2.00 ≤0.015 ≤0.003 ≥0.20 <1.2
NM500/AR500 0.10-0.40 0.20-0.45 1.00-2.00 ≤0.015 ≤0.003 ≥0.20 <1.5
NM550/AR550 0.10-0.50 0.20-0.45 1.00-1.50 ≤0.015 ≤0.003 ≥0.20 <2.0
NM600/AR600 0.10-0.50 0.20-0.45 1.00-1.50 ≤0.015 ≤0.003 ≥0.20 <2.5



Mechanical property
Grade Thickness (mm) tensile strength(MPa) Elongation A(%) Surface Brinell hardness(HBW)
NM300 ≤80 ≥1000 ≥14 270-330
NM360 ≤80 ≥1100 ≥12 330-390
NM400 ≤80 ≥1200 ≥10 370-430
NM450 ≤80 ≥1250 ≥7 420-480
NM500 ≤70 ≥470
Products Categories
Contact information
Get A Free Quote
Contact Form Demo (#3)

Abrasion Resistant Steel Plate Applications

Wear-resistant steel with high wear resistance and good impact performance, capable of cutting, bending, welding, etc., can be taken welding, plug welding, bolting and other ways to connect with other structures, with the province when in the course of the repair site , convenient, widely used in metallurgy, coal, cement, electricity, glass, mining, building materials, bricks and other industries, compared with other materials. Wear resistant steels are developed for applications where high wear resistant performance is required, such as dumper, garbage vehicle, concrete mixer truck, industrial air fan, hopper, crusher, machinery for coal, grain, cement, grab bucket, etc
(1) engineering machinery and equipment: loaders, bulldozers, xcavators
(2) handling machinery and equipment: unloading mill chain plate, hopper liner, grab the edge plate, and automatic
tipper tipping plate
(3) of construction machinery equipment: Cement pusher plate, concrete mixer liner, mixing building lining board.
Dust collector liner
(4) metallurgical machinery equipment: iron ore sintering conveying elbow, iron ore sintering machine liner,
scraper machine liner
(5) mining machinery and equipment: aggregate, stone crusher liner, blade
(6) Other mechanical equipment: sand barrel, blade, a variety of port machinery wear part
(7) of thermal power equipment: coal mill lining board Coal, coal conveying pipe, coal distributor frame, unloading
equipment lining plate
(8) shot blasting machinery: shot blasting machine lining board.

Why Choose Us Buy Abrasion Resistant Steel Plate

● Factory audit & assessment
● Packing inspection / marking verification.
● Pre-Shipment Inspection.
● After-sales services.
● Sourcing (Resistance Steel, Wear-Resistant Steel, and Weathering Resistant Steel, etc.,Tearing Corten Steel, Low Alloy Steel, Ship-Building Steel, Boiler and Pressure Vessel Steel, High Strength Steel, Bridge Steel, Anti-Seismic Steel, Z15/Z25/Z35  Carbon Steel, Stainless Steel.
● Products inspection of Straightness, Flatness, Inherent defects, Dimensions, Welding Quality, Finish/Cleanliness, material analyzing and Mechanical properties testing; MTR.

Wear resistant steel plate inspection 1 1

Our Advantage:At first, our main business is meatl material , with more and more customer cooperation , now we bought our own machine to provide cutting service to customer , we have 1 set 12000w fiber laser cutting machine , 1 set 6000 fiber laser cutting mahcine , 2 set plasma machine , 1 set bending machine , 1 set Sandblasting machine to clean the rust , and have a smaller painting room .
1).Competitive Price directly from the original manufacturer.
2).Professional QC and R&D teams to assure high quality;
3). Short lead time for building molds and manufacturing mass production;
4). Advanced measurement equipment
5). Small quantity order also is welcomed.
6).We do OEM works, as per your drawings, samples or ideas.
7).Rich experience and good technology support (have more than 10 years experience in mould design , mould manufacturing and injection).

Wear resistant steel plate inspection 2 Wear resistant steel plate inspection 3 e1727277689679

Wear resistant steel plate inspection 4 1

Abrasion Resistant Steel Plate Packing And Shipping

1.Without Packing
2.Waterproof Packing with Wooden Pallet
3.Waterproof Packing with Steel Pallet
4.Seaworthy Packing(waterproof packing with steel strip inside, then packed with steel sheet with steel pallet)

Wear resistant steel plate packingWear resistant steel plate packing and shipping

Abrasion Resistant Steel Plate Stock

Abrasion Resistant Steel Plate In Stocl

Get Free Quote of Abrasion Resistant Steel Plate

When it comes to heavy-duty applications, choosing the right materials is essential. Our abrasion-resistant steel plates are designed to deliver exceptional durability and performance, reducing downtime and maintenance costs. Perfect for a range of applications, our plates provide the protection your equipment needs.

Ready to secure your supply? Complete the message form now, and our team will provide you with competitive pricing and expert advice tailored to your needs!
